Feature:
Power supply: 240V 50HZ
Lamp: HSD-250/78, HSD-250/80, MSD-250/2
Colours: One colour wheel with 7 vivid colours and white
Gobos: One rotating gobo wheel with two metal gobos, two glass gobos and one break-up gobo. One static gobo wheel with interchangeable gobos/colour slots. Including 3 colours, 2 metal gobos and one glass gobo as well frost effect.
Prism: 3-facet prism rotating in both directions at different speed
Dimmer: DMX adjustment, 0-100%
Focus: Linear electric focus
Strobe: Variable speed strobe (1-10 flashes per second)
Pan/Tilt movement fine control: 8 Bit/16 Bit
Motors: 12 stepper motors, operating with microsteps, totally microprocessor controlled
Channels: 16 control channels (DMX512)
DMX: control board with LED display; DMX512 console (Remote switch on/off lamp via DMX512 console)
Automatic Zoom: Motorized multi-step-zoom with five different beam-angles (15°, 18°, 21°, 24°, 26°)
Safety protection: All necessary safety standard IP20 protection grade
Automatic Pan and Tilt repositioning by photoelectric repositioning system;automatic repositioning after accidental movement
Self-Resetable thermo-fuse
Moving body: PAN = 530°, TILT = 280°
Micro-step scan effect
Auto-repositioning by photoelectric repositioning system Linearity move speed adjust
Power: 500W
Dimensions: 400x400x476mm
Weight: 26 kg
